Item

Part Name

Materials

1

Body

Cast Iron: ASTM A126CL. B , DIN1691 GG25, EN 1561 EN-GJL-200; GB12226 HT200;

Ductile Cast Iron:

ASTM A536 65-45-12, DIN 1693 GGG40, EN1563 EN-GJS-400-15, GB12227 QT450-10;

2

Stem

Zinc Plated Steel;

Stainless Steel: ASTM A276 Type 316, Type 410, Type 420; ASTM A582 Type 416;

3

Thrust Washer

Carbon steel

4

Circlip

Carbon steel

5

Stopper

Carbon steel

6

Disc

DI+Rubber(EPDM or NBR)

7

O-Ring

NBR, EPDM;

8

Bushing

PTFE;

9

Key

Carbon Steel

Size

A

B

C

D

E

F

Q

T

P

L

H

J

K

S

W

 2

65

102

32

12.7

60.5

57

8

16

50

81

65

50

7

9

10

2½

72

112

32

12.7

73

69

8

16

61

97

65

50

7

9

10

3

80

118

32

12.7

89

85

8

16

76

97

65

50

7

9

10

4

100

137

32

15.9

114.5

110

9.5

16

100

116

90

70

9.5

11

12

5

118

149

32

19.1

141.5

137

9.5

16

125

148

90

70

9.5

14

14

6

140

170

32

19.1

168.5

164

9.5

16

150

148

90

70

9.5

14

14

8

175

204

38

22.2

219

214.5

11.5

19

200

134

125

102

11.5

17

17

10

215

250

38

28.6

273

268.5

13

19

250

159

125

102

11.5

22

22

12

258

275

38

31.8

324

318.5

13

19

300

165

125

102

11.5

22

24
